PostgreSQL is a powerful, open source object-relational database system used for OLTP workloads.

Mirror supports PostgreSQL as a sink, allowing you to write data directly into PostgreSQL. This provides a robust and flexible solution for both mid-sized analytical workloads and high performance REST and GraphQL APIs.

When you create a new pipeline, a table will be automatically created with columns from the source dataset. If a table is already created, the pipeline will write to it. As an example, you can set up partitions before you setup the pipeline, allowing you to scale PostgreSQL even further.

The PostgreSQL also supports Timescale hypertables, if the hypertable is already setup. We have a separate Timescale sink in technical preview that will automatically setup hypertables for you - contact support@goldsky.com for access.

​
Pipeline configuration

sinks:
  my_sink:
    description: Type.Optional(Type.String())
    type: postgres,

    # The object key coming from either a source or transform
    from: Type.String()

    # The destination schema the table is in
    schema: Type.String()

    # The destination table. It will be created if it doesn't exist.
    table: Type.String()

    # The database secret name.
    secret_name: Type.String()

    # The maximum amount of events that will be written
    # within one request. Default: 100.
    batch_size: Type.Optional(Type.Integer())

    # The maximum time (in milliseconds) the pipeline will batch events
    # for before sending. Default: '1s'.
    batch_flush_interval: Type.Optional(Type.String())

    # Enables auto commit
    scan_autocommit: Type.Optional(Type.Boolean())

    # If enabled, it will rewrite individual insert statements into multi-value insert statements,
    rewrite_batched_inserts: Type.Optional(Type.Boolean())

    # An optional column that will be used to select the 'correct' row in case of conflict
    # using the 'greater' wins strategy: - ie later date, higher number.
    # Must be numeric.
    conditional_upsert_column: Type.Optional(Type.String())

​
Role Creation

Here is an example snippet to give the permissions needed for pipelines.


CREATE ROLE goldsky_writer WITH LOGIN PASSWORD 'supersecurepassword';

-- Allow the pipeline to create schemas.
-- This is needed even if the schemas already exist
GRANT CREATE ON DATABASE postgres TO goldsky_writer;

-- For existing schemas that you want the pipeline to write to:
GRANT USAGE, CREATE ON SCHEMA <schemaName> TO goldsky_writer;

​
Secret Creation

Create a PostgreSQL secret with the following CLI command:

goldsky secret create --name A_POSTGRESQL_SECRET --value '{
  "type": "jdbc",
  "protocol": "postgresql",
  "host": "db.host.com",
  "port": 5432,
  "databaseName": "myDatabase",
  "user": "myUser",
  "password": "myPassword"
}'

​
Examples

​
Getting an edge-only stream of decoded logs

This definition gets real-time edge stream of decoded logs straight into a postgres table named eth_logs in the goldsky schema, with the secret A_POSTGRESQL_SECRET created above.

name: ethereum-decoded-logs-to-postgres
apiVersion: 3
sources:
  my_ethereum_decoded_logs:
    dataset_name: ethereum.decoded_logs
    version: 1.0.0
    type: dataset
    start_at: latest
transforms:
  logs:
    sql: |
      SELECT
          id,
          address,
          event_signature,
          event_params,
          raw_log.block_number as block_number,
          raw_log.block_hash as block_hash,
          raw_log.transaction_hash as transaction_hash
      FROM
          my_ethereum_decoded_logs
    primary_key: id
sinks:
  my_postgres_sink:
    type: postgres
    table: eth_logs
    schema: goldsky
    secret_name: A_POSTGRESQL_SECRET
    from: logs

​
Tips for backfilling large datasets into PostgreSQL

While PostgreSQL offers fast access of data, writing large backfills into PostgreSQL can sometimes be hard to scale.

Often, pipelines are bottlenecked against sinks.

Here are some things to try:

​
Avoid indexes on tables until after the backfill

Indexes increase the amount of writes needed for each insert. When doing many writes, inserts can slow down the process significantly if we’re hitting resources limitations.

​
Bigger batch_sizes for the inserts

The sink_buffer_mask_rows setting controls how many rows are batched into a single insert statement. Depending on the size of the events, you can increase this to help with write performance. 1000 is a good number to start with. The pipeline will collect data until the batch is full, or until the sink_buffer_interval is met.

​
Temporarily scale up the database

Take a look at your database stats like CPU and Memory to see where the bottlenecks are. Often, big writes aren’t blocked on CPU or RAM, but rather on network or disk I/O.

For Google Cloud SQL, there are I/O burst limits that you can surpass by increasing the amount of CPU.

For AWS RDS instances (including Aurora), the network burst limits are documented for each instance. A rule of thumb is to look at the EBS baseline I/O performance as burst credits are easily used up in a backfill scenario.

​
Aurora Tips

When using Aurora, for large datasets, make sure to use Aurora I/O optimized, which charges for more storage, but gives you immense savings on I/O credits. If you’re streaming the entire chain into your database, or have a very active subgraph, these savings can be considerable, and the disk performance is significantly more stable and results in more stable CPU usage pattern.
